Light Source
LED White light


Aiming Light
Green Dot


Image sensor
1280*800 pixels


CPU
1.2G Dual-core


Resolution’maximum’
4mils


Motion Tolerance
2M/S


Print contrast ratio’minimum’
20% Reflection Difference


Reading Angle
Pitch: 0-360°; Roll’Tilt’: ±60°; Skew ‘Yaw’: ±60°


Decoding Capability
1D: All standard 1D codes, including GS1 DataBar™ linear code can be automatically distinguished and decoded.


2D: Aztec Code; Data Matrix; MaxiCode; QRCode; HANXIN; MicroQR Code

Stack code: GS1 DataBar Expanded Stacked; GS1 DataBar Stacked; GS1 DataBar Stacked Omnidirectional; GS1 DataBar Composite; MicroPDF417; PDF417.



Reading Indicators
LED light&Buzzer’adjustable tone and volume）


Typical depth of Field
3.34mil  CODE 39  60mm—160mm


3.34mil  EAN-13  90mm—150mm

5mil     CODE39  70mm—240mm

5mil     EAN-13     70mm—230mm

13mil    UPC-A      40mm—450mm

5mil     PDF417  65mm—210mm

5mil      QR     75mm—140mm

10mil  QR   45mm—290mm

10mil  DM   30mm—260mm

20mil  QR   20mm—480mm

‘The minimum depth of field is determined by the barcode length and scanning angle. It depends on the print resolution, contrast and ambient light.’



Electrical Parameter


Current
Working current（Standard’: 280 mA  Standby current（Standard’: 130 mA


Input Voltage
5 VDC ‘+/- 10%’/500mA


Environmental Parameter


ESD protection’Air discharge’
8 kV


Drop resistance
Withstands repeated drops from 1.2m/4.0 ft onto a concrete surface.


Temperature
Working: 0 to 40 °C; Storage/Transport: -40 to 70 °C


Humidity’non-condensing’
5 – 95%


Ambient light
Indoor: 0 to 6,000 lux; Outdoor: 0 to 86,000 lux


Cordless Parameter


2.4 Transmission distance
Open space 50 meters


Bluetooth connection
15m transmission distance’basic on open space’


Communication mode
Wireless real-time transmission/wired transmission/storage mode


Battery capacity
1500mAh


Continuous working time
Full power can read over 8W commodity barcodes


Charging time
3H
