PCIe Gen3 x4 interface
NVMe 1.3 standard
Up to 2,000 MB/s read; 1,500 MB/s write
3D NAND flash memory
Engineered dynamic thermal throttling mechanism







Appearance




Dimensions
Double-sided 80 mm x 22 mm x 3.58 mm ‘3.15″ x 0.87″ x 0.14″‘


Weight
8 g ‘0.28 oz’


Type


M.2 2280






Interface




Bus Interface


NVMe PCIe Gen3 x4






Storage




Flash Type


QLC NAND flash




Capacity


1 TB






Operating Environment




Operating Temperature
0°C ’32°F’ ~ 70°C ‘158°F’


Operating Voltage


3.3V±5%






Performance




Sequential Read/Write ‘CrystalDiskMark’



1 TB

up to 2,000/1,500 MB/s





4K Random Read/Write ‘IOmeter’



1 TB

up to 170,000/250,000 IOPS





Terabytes Written ‘TBW’



1 TB

300 TBW





Mean Time Between Failures ‘MTBF’
2,000,000 hour’s’


Drive Writes Per Day ‘DWPD’
0.27 ‘3 yrs’


Note


Speed may vary due to host hardware, software, usage, and storage capacity.
The workload used to rate DWPD may be different from your actual workload, which may vary due to host hardware, software, usage, and storage capacity.
Terabytes Written ‘TBW’ expresses the endurance under the highest capacity.
Some motherboards only provide PCIe x2 connections for the M.2 slot, creating a bottleneck on even the fastest drives.






Warranty




Certificate


CE/
FCC/
BSMI/
KC/
RCM/
UKCA




Warranty


Three-year Limited Warranty




Warranty Policy


Please click here for more information about the Transcend Warranty Policy.
Warranty does not apply when SSD Scope’s lifetime indicator displays 0% within the warranty coverage.






System Requirement




Operating System


Microsoft Windows 7 or later
Linux Kernel 2.6.31 or later




Note


Systems for use with the PCIe M.2 SSD must have an M.2 connector with only an M key. B-key connectors are not compatible. Improper insertion may lead to damage. Please click here for more information.
