Operating Temp.
32° to 122° F/0° to 50° C


Storage Temp.
-40° to 158° F/-40° to 70° C


Humidity
5% to 95% relative humidity, non-condensing


Drop Specs
Withstands multiple 5 ft./1.524m drops to concrete


Ambient Lighting Tolerance
Tolerant to typical artificial indoor and natural outdoor ‘direct sunli-ght’ lighting conditions. Fluorescent, Incandescent, Mercury Vapor, Sodium Vapor, LED4: 450 Ft Candles ‘4,844 Lux’ Sunlight: 8000 Ft Candles ‘86,111 Lux’


Beeper Volume
User-selectable: three levels


Beeper Tone
User-selectable: three tones


ESD
Conforms to 15 kV air discharge and 8 kV of contact discharge







Paper Label



Code 39 – 5 mil
English: 0.25″ – 5.00″
Metric: 0.50 -12.50cm


Code 39 – 7.5 mil
English: 0 – 7.75″
Metric: 0 – 19.68cm


Code 39 – 10 mil
English: 0 – 8.50″
Metric: 0 – 21.50cm


100% UPC – 13mil
English: 0 – 8.50″
Metric: 0 – 21.50cm


200% UPC – 26mil
English: 0 – 10.25″
Metric: 0 – 26.00cm







Scanner Type
Bi-directional


Light Source ‘Laser’
650nm laser diode


Scan Rate
100 scans per second


Typical Working Distance
See chart below.


Print Contrast Min.
30% minimum reflectance


Roll ‘Tilt’: 1
± 30° from normal


Pitch: 2
± 65°


Skew ‘Yaw’: 3
± 60°


Decode Capability
UPC/EAN, UPC/EAN with Supplementals, UPC/EAN 128, Code 39, Code 39 Full ASCII, Code 39 TriOptic, Code 128, Code 128 Full ASCII, Codabar, Interleaved 2 of 5, Discrete 2 of 5, Code 93, MSI, Code 11, IATA, GS1 DataBar ‘formerly RSS’ variants, Chinese 2 of 5


Interfaces Supported
USB, RS-232; Keyboard Wedge
